DETAILS

Platform
Quick
Model Name
Quick LTD
Model Code
C31801M
FRAMESET

Frame
SmartForm C3 Alloy, SAVE, tapered head tube, Straightshot hidden cable routing, flat mount disc, rack/fender mounts, 360° reflectivity
Fork
Chromoly, 1-1/8" steerer, OutFront offset, flat mount disc, mid-blade mounts
Headset
Integrated, 1-1/4"-1-1/8"
DRIVETRAIN

Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney, 31.8mm clamp
Shifters
Shimano EF-500, EX-Fire 8-speed
Chain
KMC Z8.1, 8-speed
Crank
Shimano Tourney, 48/38/28
Rear Cogs
Shimano HG31, 11-32, 8-speed
Bottom Bracket
Cartridge, square taper
BRAKES

Brakes
Tektro MD-U310 mechanical disc, 160/160mm rotors
WHEELS

Front Hub
Formula BDC-1420, QR
Rear Hub
Formula BDC-1422, QR
Rims
Cannondale Disc, double wall w/eyelet, 32h
Spokes
Stainless Steel, 14g
Tire Size
35
Wheel Size
700c
Tires
Schwalbe Spicer, 700x35c, K-Guard, reflective strip
COMPONENTS

Handlebar
6061 Alloy Double-butted, 25mm rise, 8° sweep, 6° rise, 640mm
Stem
6061 Alloy, 31.8, 8°
Grips
Cannondale Ergo Fitness
Saddle
Cannondale Fitness Ergo Double Density
Seatpost
6061 Alloy, 27.2x350mm
